Wire cutting processing method for traffic light controller bracket in intelligent transportation system
When the traffic lights on the city roads switch accurately to ensure the orderly passage of traffic, have you ever thought that a small circuit board bracket inside the traffic light controller is silently playing a key role? In the field of intelligent traffic management systems, the processing accuracy of the circuit board bracket inside the traffic light controller directly affects the stability and reliability of the entire control system. And 800 metal wire cutting machine tool processing is becoming the core technology to overcome the processing difficulties of this key component.
In the production process of a certain intelligent traffic management system company, the circuit board bracket inside the traffic light controller is an important structural component that supports and fixes the circuit board. It needs to accurately adapt to the size and interface of the circuit board to ensure the stable installation of the circuit board in the controller. At the same time, it must have good insulation and anti-electromagnetic interference capabilities to ensure the stable operation of the traffic light control system. The bracket is usually made of high-strength insulating metal materials. While this material meets functional requirements, it also brings considerable challenges to processing.
From the specific data requirements, the dimensional accuracy of the internal circuit board bracket of the traffic light controller produced by the company must reach ≤±0.00 3 mm, the hole spacing error must be controlled within ≤±0.00 6 mm, and the surface roughness must reach Ra ≤ 0.7-1.4 μm. Such high-precision requirements make it difficult for traditional processing methods to meet production needs. First of all, high-strength insulating metal materials have high hardness and strong toughness. Ordinary cutting tools are severely worn during processing and have a short service life. Frequent replacement of tools not only increases costs, but also affects processing efficiency and accuracy. Secondly, the circuit board bracket has a complex structure, with a large number of small mounting holes, positioning grooves and special-shaped contours. Traditional cutting methods are difficult to accurately control the cutting trajectory, and dimensional deviations are very likely to occur, resulting in the bracket and the circuit board not being perfectly matched. In addition, during the cutting process, the thermal deformation of the material cannot be ignored. Even slight deformation may destroy the insulation performance of the bracket and affect the normal operation of the traffic light controller.
The 800 wire cutting machine tool has effectively solved these problems with its unique technical advantages. It generates high temperature through pulse discharge between the electrode wire and the workpiece, melts and removes the metal material to achieve cutting. The 800 wire cutting machine tool is equipped with a high-precision CNC system that can generate accurate cutting paths based on the complex design drawings of the circuit board bracket, and can accurately cut both small mounting holes and special-shaped contours. Moreover, during the wire cutting process, the diameter of the electrode wire is extremely fine, and the cutting width is only 0.1 - 0.2mm, which greatly reduces material loss and can also complete fine structure processing that is difficult to achieve with traditional processing methods. In addition, the machine tool's cooling system can promptly remove the heat generated during the cutting process, effectively control the thermal deformation of the material, and ensure the dimensional accuracy and insulation performance of the bracket.
As a leading enterprise in the industry, Zhikai CNC has invested a lot of energy in the research and development of 800 metal wire cutting machine tools. The machine tools it developed not only have the characteristics of high precision and high stability, but also incorporate intelligent technologies such as automatic programming and intelligent monitoring, which greatly improve the processing efficiency and convenience of operation. In terms of after-sales service, Zhikai CNC has achieved perfection. The professional technical team can quickly respond to customer needs and provide one-stop services such as equipment installation and commissioning, operation training, and regular maintenance, so that customers can use it without worries.
Zhikai CNC always upholds the spirit of innovation. In addition to its excellent performance in processing the internal circuit board bracket of the traffic light controller, it also has a wealth of solutions for cutting other parts of the intelligent traffic management system. For example, for the cutting of the traffic signal housing, it is recommended to use Zhikai CNC's large-size metal wire cutting machine, which can efficiently complete the processing of large workpieces; for the cutting of the traffic camera bracket, Zhikai CNC's high-precision wire cutting equipment can ensure the dimensional accuracy and structural strength of the bracket. In the future, Zhikai CNC will continue to be driven by technological innovation, and provide solid guarantees for the development of the intelligent traffic management system industry with reliable equipment and high-quality services.
Zhikai CNC has 20 years of R&D and manufacturing experience as a medium-speed wire cutting machine tool manufacturer and professional slow-speed wire cutting system solution provider. Its products are widely used in papermaking machinery: precision parts of paper cutting devices, wind power generation: metal parts of generator stators and rotors, agricultural drones: nozzle components of pesticide spraying systems, marine engineering equipment: offshore platform breakwater connectors, agricultural automation: automatic seeding machine seed distribution discs, and projects are spread across Jizhou District, Wuyi County, Jing County, Anping County, Raoyang County, Taocheng District, Wuqiang County, Shenzhou City, Zaoqiang County, Gucheng County, Fucheng County and other cities. In addition, in order to facilitate everyone to better understand the relevant knowledge of medium-speed wire cutting machine tools, we will soon launch strip-type C-type wire cutting machine tools, micro high-rigidity wire cutting machine equipment, 1-meter brand wire cutting machine, 800 machine tool medium-speed wire cutting machine tools, large high-end wire cutting machines, DK7735 machine tool spark wire cutting, strip-type wire cutting machine tool wire cutting, large large-angle medium-speed wire cutting machine tools and other related popular science articles. Welcome everyone to visit and obtain relevant solutions.
